Features:

Carbon Fiber Rotor

The carbon fiber rotor, passed 100,000 times life service test, features light weight, chemical corrosion resistance, high mechanical strength, long service life, larger capacity as well as high speed (6x1000ml/9000rpm), providing high efficient and perfect product for bio-pharmacy, biological products, chemical industry etc.

Super-large capacity with high efficiency

Blood bank: Blood bags are provided with various cups for flexible sample process. It can spin 6 or 8x550ml, 8 or 12x450ml, 12 or 16x300ml, 18 or 24x200ml triple blood bags to meet the demand of current and future sample process. Standard interface is provided to be linked to the system of blood bank.

Pharmaceuticals and chemical products: It can process samples with the capacity of 8x1500mL, 6x2400mL or 8x2000mL. The capacity of 16L at a single sample process is the largest one in the centrifuge market, efficiency greatly improved.

Safety performance

With the function of non-contact imbalance protection, automatic rotor identification, over-speed, over temperature, motor overheat and door lid protection, so as to provide safe guard for sample, centrifuge as well as the operator.

High sensitivity touch screen & super control system

1. HD and bright touch screen can be operated with your gloved hand: Simplify laboratory-set and test operation process. Setting parameters(speed,time,temperature) and actual running parameters can be displayed on the screen simultaneously with easy readout.

2. Curve operation mode: the speed and temperature can be directly displayed through the curve, which is more stable and intuitive to observe the speed and temperature changes.

3. Program setting: The program can easily achieve the reproducibility of the experiment. Program naming is easily accessible to the user, which is easy to reproduce the whole scheme the experiment only by calling the corresponding name. It can support 5-steps centrifugation to meet the diversified experimental needs. The user’s experimental scheme can be perfectly operated by one key.(100 programs and each program can be divided into 5 steps. More programs can be saved by adding the external memory card.)

4. Authority management: Different permissions can be assigned to different users and roles. It has password protection function to enhance the authority management of operators. Language management: the Chinese and English interfaces are suitable for laboratory personnel in most countries. (The authority list can be customized according to the needs.)

5. Super system management tool: different operation options are available for different applications, such as: The run graph button can switch the main interface to curve interface, and the user login button requires the log in for different authority.

6. Data records: Data traceability management, running history records, diagnosis records can be checked on the screen or exported by USB port and saved to the relevant storage devices, which can ensure the data integrity.

7. Featuring 10 acceleration profiles and 11 deceleration profiles to prevent second emulsion or turbid and achieve the best centrifugal effect (no more than 30 profiles can be customized according to special requirements).

8. Manual input sample number or automatic scanning to check the centrifuging record of each sample.

Technical Parameters
