Features: 1. 37 Sample positions. 2. 28 Reagent positions. 3. 48 Reaction cuvettes. 4. 200 Tests per hour. 5. Probe anti-collision function,liquid level dectection function.
Introduction:
It is used to quantitatively analyze the clinical chemistry of human serum, plasma, urine, cerebrospinal fluid and other samples. Do not use for other purposes.
Models:
| Model | BW-200 | |
| Overall | Throughput | 200 Tests/hour |
| Performance | Analysis Method | End-point, Fixed-time, Rate(Kinetic) |
| Certificates | CE, FDA, ISO9001, ISO14001, ISO13485 | |
| Sample & Reagent System | Sample Positions | 37 sample positions |
| Reagent Position | 28 reagent positions | |
| Sample Volume | 2-70µl | |
| Reagent Volume | 20-350µl | |
| Probe | Teflon coating, with anti-collision function, liquid level detection function | |
| Probe Washing | Automatic washing interior and exterior | |
| Reagent Cooling | Refrigerated tray with independent switch | |
| Reaction System | Temperature Control | 37+0.2℃, real-time monitoring |
| Cuvettes | 48 reusable cuvettes,optical length 6mm | |
| Mixer Probe | Independent stirring | |
| Washing | Automatic cuvettes washing | |
| STAT function | YES | |
| Optical System | Light Source | 6V/10W halogen lamp |
| Spectrophotometry | Post-spectral spectrophotometry | |
| Wavelength | 340,405,450,480,505,546,570,600,,630,700,750,800nm | |
| Absorbance | 0-3.0Abs | |
| Calibration & QC | Calibration | Linear:K factor, 1-point ,2-point and multipoint linear Non-Linear:Spline,Polygon, Index, Ogarithm, Logit-4P, Logit-5P |
| Quality Control | Real-time QC, Westgard multi rule, Cumulative Sum Check,Twin Plot(2D) | |
| Data Management | Software | Windows 7/8/10 , 32or 64bit |
| LIS System | Bi-direction,support HL7 protocol | |
| Interface | LAN port access | |
| Printer | External,multiple reporting mode available | |
| Working Conditions | Power Supply | AC220V±10%,50/60Hz, 110V±10%,60Hz, 300W |
| Temperature | 15～30℃ | |
| Water Consumption | Deionized water:＜5L/H | |
| Humidity | 40-85% | |
| Size & Weight | External Size (W*D*H) | 625*425*460mm |
| Net Weight | 36kg | |
| Package Size (W*D*H) | 728*530*884mm | |
| Gross Weight | 55kg | |
