Features: 1. Water tank for humidity in the chamber. 2. Air jacket:equipped with UV Lamp for sterilizing; Water jacket: equipped with HEPA filter. 3. Equipped with USB port and LCD touch screen, the incubator can save data in real time. 4. High quality CO2 gas filter ensures the inside gad quality. 5. SMC brand gas circuit valves ensure more stable CO2 concentration and less consumption of CO2 gas. 6. Microcomputer controller，LED displays temperature,CO2 concentration ,run-time and timing. 7. High quality infrared sensor for accurate CO2 concentration. 8. The working chamber adopts round angle structure , easy to clean.
Introduction:
Carbon dioxide (CO2) incubators provide optimal growing conditions and contamination prevention for valuable cell cultures.We provide a wide range of CO2 incubators, ranging from a small capacity and volume to a large scale capacity cabinet. All the CO2 incubators are build with the patented Water Jacket and Air Jacket systems, which minimizes the risk of condensation at the present and in the future.
Models:
Model | BJPX-C50 | BJPX-C80 | BJPX-C160 | ||
Capacity | 50L | 80L | 160L | ||
Heating | Air jacket | Air jacket | Water jacket | Air jacket | Water jacket |
Temp. Range | RT+5~60 ℃ | ||||
Control Type | Microcomputer controller | ||||
Temp. Fluctuation | ≤±0.2℃(at 37℃) | ||||
Temp. Uniformity | ≤±0.3 ℃(at 37℃) | ||||
Time Setting | 999h or continuous | ||||
Alarm | Audible and visual alarm; Over-temperature alarm; CO2 Concentration alarm. | ||||
Shelves | 2 pcs/ adjustable | ||||
Material | External cold-rolled steel with painting; Internal stainless steel | ||||
Door | With inner door and external door | ||||
CO2 Range | Infrared sensor, range 0~20% | ||||
CO2 Control Resolution | 0.1% | ||||
Humidification Type | Water tank for natural evaporation | ||||
Sterilization Type | UV lamp | ||||
Ambient Temp. & Humidity | 18~30℃, suggest 25±2℃; Relative humidity ≤80% | ||||
Caster | Foot master caster | ||||
Consumption | 350W | 600W | 875W | 650W | 1000W |
Power Supply | AC220V±10%, 50/60Hz(Standard); AC110V±10%, 60Hz(Optional) | ||||
Internal Size(W*D*H)mm | 337*338*443 | 377*410*524 | 428*412*522 | 477*473*711 | 528*512*722 |
External Size(W*D*H)mm | 500*527*821 | 600*596*921 | 647*593*1070 | 700*666*1101 | 747*694*1260 |
Packing Size(W*D*H)mm | 655*685*970 | 735*735*1070 | 725*780*1225 | 795*835*1250 | 824*877*1425 |
Gross Weight(kg) | 68 | 83 | 108 | 108 | 145 |
