Features
1. Higher precision of temperature control
2. Faster heating and cooling speed
3. Better block temperature uniformity
4. Smaller instrument dimension
5. More silent operation environment
6. Advanced thermoelectric cooling technology and creative TAS technology
7. Technical Parameters:
Model | BW-EO | BW-TC |
Sample Capacity | 96-PCR plate(full-skirted) 96*0.2ml tubes 12*8-strip | |
Cooling Technology | Peltier-based | |
Display | LCD display and touch creen(5.7 inch) | 6.5 inch, 262 144 color LCD display and touch screen |
Temp. Range | 4.0~99.9℃ | |
Heating Speed Of Ramping | Up to 4℃/sec | |
Cooling Speed Of Ramping | Up to 4℃/sec | |
Temp. Uniformity | ≤±0.3℃ | ≤±0.2℃ |
Temp. Accuracy | ≤±0.1℃(50℃), ≤±0.2℃ (≥90℃) | |
Temp. Control Modes | BLOCK or TUBE | |
Ramping Range Adjustable | 0.1℃~4℃ | |
Memory | ≥250 typical programs onboard, unlimited with USB flash drive expansion | |
Max. No. Of Cycle | 99. Suitable for nested PCR | |
Time Up/Down | 0~9 min59s, suitable for long PCR | |
Temp. Up/down | 0~9.9℃,suitable for touchdown PCR | |
Auto Pause/Power Protection | yes | |
Soak Function | Yes | |
Gradient Range Of Temp. Difference | 1~30℃ | |
Gradient Range | 30~99.9℃ | |
Hot-lid Temp. Range | Room temperature +5℃~110℃(default 105℃) | |
Height Of Hot-lid | Automatic Adjusted | |
Auto Shut-off Function Of Hot Lid | While block temperature is lower than set temperature or program ends, the hot-lid will be automatically closed | |
Communication Interface | USB | LAN |
Power Supply | 100~240V, 50/60Hz, 600W | |
Dimension | 335*260*270mm | 345*260*270mm |
Packing Size(L*W*H) | 495*410*395mm | 495*410*395mm |
Gross Weight | 10.5kg | 12.5kg |
Certificates | Ferrotec Peltier/CE/RoHS2.0 | |
